1.Application:
HY0381A ASTM Yarn Examine Machine is used to assess the evenness, hairiness, neps and other imperfections in a representative sample of various yarn wound at a pre-determined yarn density onto a quadrate/tapered black board.
2.Standards:
ASTM D2255 | GB/T 398, 5324, 9996 | FZ/T 32004, 32005 |
3.Features:
★ Driven by synchronous motor, and digital controlling circuit, ensure uniform pitch during a test
★ Various pitch to satisfy comprehensive requirements of different yarn linear density
★ Two type board for selection, White board for colored yarn (HY381A)
★ Equipped with alternative pre-tension
★ Auto-stop function
★ Adjustable winding speed
★ The material of board is aluminum, it's more durable.
4.Technical Specification:
Model | HY0381A ASTM Yarn Examine Machine | ||
Black board size | 575mm ×250mm ×160mm (L×W×W) | ||
Yarn winding density | 7, 9, 11, 13, 15, 19wraps/cm | ||
Rotational speed | 10~400RPM (adjustable) | ||
Power supply | 220V, 50Hz, 40W | ||
Dimensions | 1000×370×300mm | ||
Weight | 35Kg | ||
5.Standard Configuration:
No. | ASTM Yarn Examine Machine | Quantity |
1. | Main machine | 1set |
2. | Black board | 1 pcs |
3. | Packing list | 1 pcs |
4. | Quality certificate | 1 pcs |
5. | User manual | 1 pcs |
6.Optional Configuration:
No. | Item |
1 | ASTM Assessment photo scale |
2 |
